Custom Precision Machining, Milling and Turning Parts for Medical Devices
NEST HOLDER 6061-T6 Clear Anodizing for Dental Equipment
Precision is non-negotiable in the medical field. Whether it’s a prosthetic joint, dental implant, or a surgical tool, every component must meet rigorous specifications. Medical CNC machining ensures precision and quality control, vital for safe and effective patient devices.
Products Details
| Part | Application | Machining Process Used | Material | Specific Feature |
| Rotor | Blood Gas Analyzer | 4-Axis Milling | 6061-T6 Aluminum | 0.010" Thick Cell Walls |
| Rotor Housing | Blood Gas Analyzer | 4-Axis Milling | 6061-T6 Aluminum | Micro Milling of Housing to Accept Electronics |
| Stator | Blood Gas Analyzer | 3-Axis milling | 6061-T6 Aluminum | Circle Interpolate Boss with 0.0005" Tolerance |
| Objective Head | Catheter Head | EDM Sinker | 17-4PH Steel | EDM Sink with Miniature Copper Electrodes |
| Barrier | CT Scanner | Conventional Turn and Mill | 718 Inconel | Used Ceramic Tooling for Turning |
| Arc, Support | CT Scanner Rail | 4-Axis Milling | Project 70 Steel | Drilling and Tapping Holes on the Face of a 48" Radius |
| Impeller | Fluid Flow | 5-Axis Milling | PEEK | Burr-Free Micro Milling |
| Micro-Tip | Instrument Cap | Micro Turning | AISI 316 Stainless Steel | Micro Wire EDM |
| Gear Plate | Laser Eye Keratome | 4-Axis Milling | 17-4 Ph Cond H900 | Mill to Accept Miniature Gears |
| Insulator, Conductivity | Element Isolator | Mill/Turn | Kel-F PCTFE Plastic | Turn Tapered ID Profiles |
| Impeller, Polished | Experimental Heart Pump | 5-Axis Milling | 6Al-4v Titanium | Burr Free Polished Impeller Surface |
| Alignment Screw | CT Scanner | Swiss Screw Machine | 718 Inconel | Burr Free Part for Clean Room Use |
| Nozzle, Dispensing | Drug Dispensing Nozzle | Hard Turning | 17-4 PH Cond H900 | EDM Wire 2mm Thru-Hole over 8 " Length |
| Chamber | Pneumatic Drill Core | Eccentric Turning | 17-4 ph Cond H900 | Honing ID to 8 Micro Finish |
Do you need even faster turnaround on your Dental Equipment, Medical devices, Biotechnology, etc? Discover the difference with our precision medical components, get your quote now!contact us at mitani@rymachining.com
